10KVDC silicone rubber cable
Wellde®
Support
AWG/Color/Length
Product Overview
Wellde high-voltage DC silicone wire is specially developed for 10KV DC high-voltage working conditions. It uses a thick silicone rubber insulation layer and multiple strands of tin plated copper conductors, with outstanding insulation and voltage resistance capabilities, while retaining the excellent flexibility of silicone cables.
Product Information
Item | Specification Details |
|---|---|
Brand | Wellde |
Product Name | 10KV DC High Voltage Silicone Wire |
Conductor Material | Stranded Extra-fine Tinned Copper Wires |
Insulation Material | Thickened Silicone Rubber |
Rated Voltage | 10KV DC |
Sample Gauge | 16AWG |
Operating Temperature | -60℃ ~ +200℃ |
Stock Color | White, other colors available on custom request |
Environmental Standard | RoHS compliant, test report available |
Product advantages
1. Ultra high DC withstand voltage: rated at 10KV DC, thickened silicone rubber insulation layer effectively prevents breakdown and ensures safe operation under high voltage conditions.
2. Excellent temperature resistance: It can work in the range of -60 ℃~200 ℃, with insulation not softening at high temperatures and no hardening or cracking in low temperature environments.
3. Conductor conductivity stability: Multiple strands of ultra-fine tin plated conductors are twisted together, with strong flexibility, oxidation resistance, and repeated bending, making it difficult to break the core.
4. Flexible customization capability: AWG wire gauge is optional, supporting customization of outer skin color, printing content, cutting length, and can be OEM manufactured.
FAQ
Q1: Can this 10KV silicone wire be used in AC 10KV scenarios?
A1: This product has a DC 10KV specification and cannot be directly used in 10KV AC scenarios.
Q2: What should be paid attention to when wiring high-voltage silicone wires?
A2: Sufficient safety distance should be reserved for high-voltage wiring to avoid sharp scratches on the outer skin; When bending, do not exceed the minimum bending radius to prevent damage to the insulation layer.
Q3: Can we customize high-voltage silicone wires with different AWG specifications?
A3: Yes, it supports customization of multiple AWG wire gauges, and the insulation thickness corresponding to different wire gauges will be adjusted synchronously to ensure that the withstand voltage meets the standard.
Q4: Can we provide samples for testing voltage resistance?
A4: Support sending samples for customers to conduct tests such as pressure resistance and bending.
