Product Information Sheet
Item | Specification Details |
|---|---|
Conductor Material | Stranded bare copper conductor |
Inner Insulation | PTFE film wrapped insulation |
Shield Structure | Tinned copper braided shield, 100% coverage |
Rated Voltage | 600V |
Operating Temperature Range | -200℃ ~ +260℃ |
Key Features | High temperature resistance, EMI shielding, chemical resistance, low dielectric constant, anti-oxidation braid shield |
Recommended Application | Industrial high-temperature sensors, thermocouple extension wires, oven internal wiring, semiconductor equipment, airborne wiring harness, high-temperature test fixture, high-temperature signal circuits requiring anti-interference |
Compliance Documents | RoHS, factory test report |
FAQ
Q1: How to choose PTFE shielded high-temperature wire and silicone shielded high-temperature wire?
A1: PTFE has a higher upper limit of temperature resistance and stronger resistance to chemical solvents; Silicone wire is softer and more cost-effective. If the environment is above 200 ℃ or in contact with chemical reagents, PTFE shielded wire is preferred.
Q2：Will a 100% weaving coverage make the outer diameter of the wire larger?
A2: The weaving process is tight and will not excessively increase the outer diameter; We can adjust the weaving wire diameter according to the customer's outer diameter requirements.
Q3: What is the minimum order quantity?
A3: Regular specifications support small batch orders, samples can be tested first, and bulk purchases can provide tiered discounted prices.
Q4: Can the shielding layer be used as a grounding lead wire?
A4: Yes, we can pre process the shielded grounding wire to reduce the number of wire harness processing steps for customers.
